2019-06-27 Release Notice DEWETRON Battery Management Tool 1.6

Battery management tool for any DEWE/DEWE2 chassis with BAT-option.

* Version: 1.6

* Components incl. in the installer:

Battery Management Tool v1.6

LabVIEW Run-Time Engine 2016 (64-Bit)

NI-VISA Run-Time Engine 17.0

Microsoft .NET Framework 4.6.2

* Features:

** battery management: status indication, charging overview, power consumption overview

** fan control for all D240/300-UPS solutions: temperature control and fan control

** independent from the measurement software

** no interaction, no measurement channels for the batteries

* Supported Hardware:

** up to 4 installed batteries

** DC power supplies D300UPS and D240UPS

** all OceanServer battery controller, tested with XP04

** and any combination of above

**   DEWE2: DEWE2-A13, DEWE2-A7, DEWE2-M13s, DEWE2-F13s

**   DEWE: DEWE-501, DEWE-510, DEWE-571, DEWE-2600, DEWE-3020, DEWE-5000

**   DC power supply: DEWE2-UPS-250-DC, DEWE-UPS-150-DC, DEWE-UPS-300-DC

* Requirements:

** Windows 10 64-Bit

** Windows 7 64-Bit

* Installation Procedure:

** exit/close application and run installer

* New Features and most important bugfixes:

** support of new XP04 OCS firmware with complete battery shut-down

** 64-Bit OS version only

* Known Limitations:

** none

+ + + + + + + + + + + + + + + + + + + + + + + + + + + + + + + +

2019-07-30 Release Notice DEWETRON CPAD Setup Tool 1.6.0

Module and Channel Setup Tool for all CPAD-Modules with dbc-file generation

works with:

  DEWE2 (TRION-CAN-2-D, TRION-CAN-4-D, TRION-MULTI, TRION-1600-dLV-xx-D-CAN, TRION-1802-dLV-xx-D-CAN)

  TRIONet (TRION-CAN-2-D, TRION-CAN-4-D, TRION-MULTI)

  DEWE DAQ (xx1, xx3, xx5)

  DEWE DSA (xx1, xx3, xx5)

  Peak USB adapter

* Version: 1.6.0

* Components:

** CPAD Setup tool.exe 1.6.0

** CPAD bus limits.pdf

** CPAD setup tool user reference.pdf

** epad2_cpad2_cpad3_modules_103ex.pdf

** LabVIEW runtime engine 2016 (64bit)

* Files:

** CPAD Setup tool.zip

* Requirements:

** Windows 10 64-Bit or Windows 7 64 Bit

** for use with PEAK adapter: PEAK hardware driver version 3.13.0.15462 or later

* Installation procedure:

** run installer (over existing CPAD tool)

** alternatively: uninstall previous version in Windows system control panel

* New Features and most important bugfixes:

** support of new TRION hardware with CAN port on ch1

TRION-1820-MUILTI-4-D

TRION-1850-MULTI-4-D

TRION3-1820-MULTI-4-D

TRION3-1820-MULTI-8-L0B

TRION3-1850-MULTI-4-D

TRION3-1850-MULTI-8-L0B

** minor translation fixes in German version

* Known Limitations:

** CPAD3 modules: FW version 2.2 or higher

** unstable communication at 1 MBaud (= max baud rate) when all ports are used

* !!Important Info!!:

When used with TRIONet, make sure the Windows firewall is disabled, or define an exception rule or make sure upon popup warning to ALLOW access through firewall.

In the setup dialog, CHECK the box for TRIONet support and enter the IP address of the Computers LAN port (NOT of the TRIONet)

Do not use in combination with DEWESoft BatMan Plugin
